The Fusion Splicer is used for splicing two optical fibers end-to-end by fusion. It is an indispensable tool for fiber OSP and indoor cable network installation. There are many models of fusion splicers available, varying in features and capability and cost. With hundreds of options to choose from, this task can become very difficult in choosing the right splicer for the job. In this article, we will discuss about how to find the best fusion splicer for your application in the following aspects.
In the market, the famous brands for fusion splices are Fujikura, Sumitomo and Furukawa from Japan, Comway from USA,INNO from Korea, DVP and TEKCN from China.
To help you find the fusion splicer brand, we analyzed & researched all the features that are right for you and came up with a list of 10 different options to purchase.
Check out the thorough reviews of the best fiber fusion splicer in 2022 below.
List of The Best Fiber Fusion Splicer
Fujikura 90S+ Fusion Splicer:
Fujikura 90S+ is a fusion splicer with high precision lenses, which provide an accurate core-to-core alignment. Also, these lenses allow the splicer to discriminate between fiber types.
The 90S+ possesses advanced image processing technology which analyzes the profile of the fiber image as a brightness pattern. The tool finds the true core position and achieves consistent lower splice loss. The device features fiber discrimination function: it automatically identifies the optimum arc discharge parameters in accordance with the fiber type.
Fujikura 90S+ has faster automated features that reduce installation time. The user can complete the entire splicing process without touching the tool and only moving the fiber. The fiber retention clamps support the automated operations. When the sheath clamps open automatically after splicing, the fiber retention clamps gently hold the spliced fiber to keep it from flying out.
Features
* Splicing time: 7-9 sec (SM FAST mode).
* Heat time: 13-15 sec (for 60 mm sleeves).
* Core alignment technology.
* Advanced image processing technology.
* Fiber discrimination function.
* The faster automated features.
* Time for opening wind protector is 80% lower compared to the Fujikura 80S.
* Time for placing fiber into heater is 50% lower compared to the Fujikura 80S.
* Easy fiber protection sleeve positioning.
* The lid of the carrying case may be used as a work table.
* Plenty of space in the carrying case. There are two drawers for storage, and the work tray can be divided into two separate places.
* The sheath clamp is compatible with loose tube fiber.
* Wireless data connectivity allows automatic cleaver blade rotation when the splicer judges the blade is worn.
* The tool can connect two cleavers simultaneously.
* Blade life management: the device displays the remaining blade life, informs about blade height and position change, and when new blade is required.
* Operation manual is installed into the splicer.
* Battery life increased up to 500 recharge cycles.
* Increased electrode lifetime – up to 5000 splicing cycles with one set.
* 5-inch color TFT touch screen display.
Fujikura 88S Fusion Splicer:
Fujikura 88S is a fusion splicer with a high precision lenses, which provide an accurate core-to-core alignment. Also, these lenses allow the splicer to discriminate between fiber types.
The 88S possesses advanced image processing technology which analyzes the profile of the fiber image as a brightness pattern. The tool finds the true core position and achieves the consistent lower splice loss. The device features fiber discrimination function: it automatically identifies the optimum arc discharge parameters in accordance with the fiber type.
Fujikura 88S has faster automated features that reduce installation time. The user can complete the entire splicing process without touching the tool and only moving the fiber. The fiber retention clamps support the automated operations. When the sheath clamps open automatically after splicing, the fiber retention clamps gently hold the spliced fiber to keep it from flying out.
Features
* Splicing time: 7-9 sec (SM FAST mode).
* Heat time: 13-15 sec (for 60 mm sleeves).
* Core alignment technology.
* Advanced image processing technology.
* Fiber discrimination function.
* The faster automated features.
* Time for opening wind protector is 80% lower comparing to the Fujikura 80S.
* Time for placing fiber into heater is 50% lower comparing to the Fujikura 80S.
* Easy fiber protection sleeve positioning.
* The lid of the carrying case may be used as a work table.
* Plenty of space in the carrying case. There are two drawers for storage, and the work tray can be divided into two separate places.
* The sheath clamp is compatible with loose tube fiber.
* Wireless data connectivity allows automatic cleaver blade rotation when the splicer judges the blade is worn.
* The tool can connect two cleavers simultaneously.
* Blade life management: the device displays the remaining blade life, informs about blade height and position change, and when new blade is required.
* Operation manual is installed into the splicer.
* Battery life increased up to 500 recharge cycles.
* Increased electrode lifetime – up to 5000 splicing cycles with one set.
* 5-inch color TFT touch screen display.
Fujikura 41S Fusion Splicer:
Fujikura 41S is a V-groove cladding alignment fusion splicer for SMF(G.652/657), MMF(G.651), DSF(G.653), NZDSF(G.655) single optical fibers. Typical splice time: 6-9 seconds, typical tube heating time: 16-24 seconds. Bluetooth® 4.1LE wireless connectivity improves efficiency and reduces maintenance time.
Fujikura 41S is able to estimate the splice loss as accurately as possible. Also, the device is equipped with a touch panel for easy operation, and comes in a multifunctional case with integrated workstation.
Features
* Active V-groove splicer.
* Typical splice time: 6-9 seconds.
* Typical tube heating time: 16-24 seconds.
* Equipped with CT-50 cleaver.
* Easy protector positioning.
* Bluetooth capability connection.
* Core loss estimation function.
* Touch panel with easy operation.
* Multi-functional carrying case with integrated work station.
Sumitomo Type-82C+ Fusion Splicer:
Sumitomo Type-82C+ is a direct core monitoring fusion splicer for ultra fast splicing in any environment.
Features
* Ultra fast splicing: 5 sec.
* Ultra fast heating: 9 sec.
* Automatic fiber identification (SMF, MMF, DSF, NZDSF, BIF, other).
* Automatic arc calibration.
* G.657 fiber auto-splice function.
* Supports bi-directional splicing operation.
* Dust-resistant, water-resistant and shock-proof.
* Compact & lightweight (only 1.9 kg).
* Touch-screen operation.
* Upgrades software via internet.
* Remote interactive maintenance via internet.
* Equipped with onboard user training video.
INNO Instrument View 7 Fusion Splicer:
INNO Instrument View 7 is a core-to-core alignment digital fusion splicer with 8 seconds splicing time (auto-mode), 13 seconds tube heating time designed for splicing SM, MM, NZDS optical fibers.
The INNO Instrument View 7 kit includes all the necessary accessories: high capacity battery, high precision fiber cleaver, electrode and many more items in a carrying case.
Features
* Core alignment splicing method with DACAS (Digital Analysis Core Alignment System).
* The world's highest magnification and resolution.
* 5-inch high-resolution color LCD touch screen.
* Ultra-high capacity battery.
* Fast heating time.
* Detachable SOC holder and heating oven.
* Ceramic clamp for improved durability.
* Easy to replace electrodes.
* Protective rubberized cover
* Increased water, dust and shock resistance, may be used under severe environmentalal conditions.
Signal Fire AI-9 Fusion Splicer:
The AI-9 Fusion Splicer implements cutting-edge core alignment technology along with 6 motors and autofocus. It is one of the best fiber fusion splicer because it serves as a new generation of fiber fusion splicers and is equipped with various advanced features. Typically, it is used for security monitoring, FTTH projects, and many other fiber cable splicing projects.
With the use of a quad-core CPU and due to fast response times, this splicing machine is one of the fastest ones on the market. You can precisely note the output from its 5-inch display screen that boasts 800 x 480 pixels resolution. The overall efficiency is 50% higher than the common splicing machines. Based on your preferences, you can switch between 10 languages, i.e. English, Russian, French, Portuguese, Italian, Spanish, Polish, Arabic.
Features
* Various fiber types it can support are MM, SM, pigtail, bare fiber, multi fiber cable, and rubber-insulated fibers.
* The splice loss for SM, MM, and DS/NZDS fibers are respectively 0.025 dB, 0.01 dB, and 0.04 dB.
* The cladding diameter-r is 80-150μm and the coating diameter is 100-1000μmm.
* Fiber cleave length is 8-16 mm (for coating less than 250µm) and 16 mm (for coating less than 250-1000µm).
* Built-in visual fault locator has a power rating of 15 mW. It supports constantly bright mode and flashing mode.
* The focus magnification is up to 300 times.
* The fast splicing completes in 5seconds and the fast heating time is 15 seconds.
Comway C10S Fusion Splicer:
Comway C10S is a fusion splicer and a fiber endface melter, all in one. It is a powerful and stable tool with 6 motors which enable precise core alignment. The splicer is used for splicing SM (ITU-T G.652), MM (ITU-T G.651), DS (ITU-T G.653), NZ / NZDS (ITU-T G.655), BI (ITU-T G.654) fibers, and also for splicing EB (ITU-T G.654) used in 5G installations. The tool is equipped with a high-performance heater that provides a faster and more power-saving machining process, and a stable and durable ceramic fiber presser.
The large capacity battery and resistance to the most unfavorable environment conditions (high temperature, humidity, altitude, and wind velocity) allows using Comway C10S in the field. The high-quality tool's screen ensures clear viewing of results even under bright sunlight.
Features
* 2 in 1: a fusion splicer and a fiber endface melter.
* Used for splicing EB (ITU-T G.654) fibers used in 5G installations.
* Six motors enable precise core alignment.
* Smart ARC control technology provides stable work under any conditions.
* Splicing time: 5 seconds; heating time: 8 seconds.
* Fast and power saving high-performance heater.
* Up to 750x fiber magnification when viewing the X or Y axes separately.
* Stable and durable ceramic fiber presser.
* Low power consumption.
* The high-quality screen ensures clear viewing of results even under bright sunlight.
* Removable large capacity battery. Fully charged performs over 500 times splicing and heating.
* Waterproof. Dustproof. Anti-shock (1 m.)
DVP-740 Fusion Splicer:
DVP-740 is an automatic fusion splicer for SM, MM, DS, NZ-DS(G655), EDF and other fibers. The DVP-740 is capable of ensuring high-quality splicing even in the most unfavorable environment conditions.
Features
* 4.3-inch color display.
* Fully automatic, semi-automatic and manual operation.
* Can be applied for fibers, cables and SOC (splice-on connectors).
* User-friendly menu.
* High-quality operation under wind and rain, dust and water protection.
* Stress-resistance.
* Compact dimensions and light weight.
* Menu languages: English, Spanish, German, Russian, Korean, Portuguese, French.
TEKCN TC 600 Fusion Splicer:
Features:
* 6 motors core alignment
* Smart Anti-Counterfeit electrodes
* UItra low splice loss
* GPS track
* Stable performance, long duration
* New GPU System, energy Saving
* Full HD capacitive touch screen
JETFIBER H5 Fusion Splicer:
Features:
* Core alignment fusion splicer
* 6 secs. splicing time.
* 12 secs. Heating time.
* Max. 300X fiber magnification.
* Smart-connected APP.
* Splicing record management.
* Intelligent burglar-resisting system.
* Three-dimensional protection cover.
* Reduce risk and unpredictability.
* Handy. light weight. anti-dropping solid and durable.
* Hi-speed USB connection internet remote control.
* Splice loss: SM:0.02dB,MM:0.01dB,DS:0.04dB,NZ/NZDS:0.04dB,BI:0.02dB.
* Core-to-core alignment system compatible with all sorts of optical fiber types.
* 4000mAh battery capacity over 240 times splicing and heating.
