Skycom Hi-Precision Fusion Splicer T-208H
Skycom Hi-Precision Fusion Splicer T-208H
Couldn't load pickup availability
SKYCOM FUSION SPLICER T-208H
- High Speed: 9 Secs Rapidly Splicing, 25 Secs Quick Heating;
- Greater Accuracy: Digital Imaging and Vision Processing Metrology;
- 5 inches high Resolution colorful LCD display;
- 3-in-1 Universal Holder: Applicable Cleaved Length up to 5mm;
- 5200mAh, Ultra-high Battery;
- Multistage Amplification, Magnification up to 520X Which Makes Clear Image
Specifications
|
Applicable Fibers |
SM, MM, NZ-DS, EDF, Pigtail, FTTH drop cable SC/LC/FC connector (optional function) |
|
Average Splice Loss |
0.02dB(SM), 0.01dB(MM), 0.04dB(NZDS), 0.04dB(EDF) |
|
Return Loss |
≥60dB |
|
Quick Splicing Time |
9 seconds |
|
Quick Heating Time |
25 seconds |
|
Splicing mode |
Full-automatic , automatic, manual |
|
Heating mode |
Automatic, manual |
|
Splicing Program |
50 groups |
|
Operating Language |
Chinese, English, French, Portuguese, Spanish, Russian |
|
Operating Conditions |
-10~+50°C(operation temperature),0~95% RH(humidity), 0~5000m(altitude) |
|
Monitor |
5 inches high resolution colorful LCD display |
|
Fiber Image |
X or Y axis Separately views with 360 times magnification, or Simultaneously 220 times |
|
Estimated Splice |
Available |
|
Tension Test |
2.0N(200gf)(Standard) |
|
Storage of Splice Result |
6,000 groups of latest splice results |
|
Power Supply |
AC adaptor: 100~240V input voltage, 50/60Hz; 12V, 5A output voltage(DC) ;Inner lithium battery: 11.1V, 5.2Ah |
|
Optical Fiber Fixture |
3-in-1 cutting fixture; Multipurpose 1+N fixture (Optional for SC/LC/FC connector) |
|
Dimensions |
130(W)*135(D)*130(H)mm; Package size: 52*32*30cm |
|
Weight |
1.75kg (without battery pack) |
Package Includes
Fusion Splicer T-307H | Fiber Cleaver | Spare Electrode
Wire Stripping Pliers | Fiber Stripper | Carrying Case
Cooling Tray | Straps | Power Adapter | User Manual
