5 in 1 PON Power Meter Fiber Cable Testing Instrument Pass or Fail Function 1310 1490 1550nm In Service GPON EPON Live Checking
5 in 1 PON Power Meter Fiber Cable Testing Instrument Pass or Fail Function 1310 1490 1550nm In Service GPON EPON Live Checking
Couldn't load pickup availability
5 in 1 PON Power Meter Fiber Cable Testing Instrument Pass or Fail Function 1310 1490 1550nm In Service GPON EPON Live Checking
TFT color screen , display delicate
Synchronous test and display of voice , data and video signal
1310/1490/1550n in PON system can be measured
Pass/Fail threshold and calirabtion wave can be set
Chinese/English diplay optional
Burst mode for 1310nm upstream wave
Support VFL/RJ45 sequence, length tracker
1 Visual Fault Locator
3 RJ45 Cable Sequence Function
4 RJ45 Cable Tracker Function
Specification
Standard wavelengths |
1310nm |
1490nm |
1550nm |
(upstream) |
(downstream) |
(downstream) |
|
Pass zone(nm) |
1260~1360 |
1470~1505 |
1535~1570 |
Range(dBm) |
-50~+10 |
-50~+10 |
-45~+23 |
Isolation @1310nm(dB) |
|
>40 |
>40 |
Isolation @1490nm(dB) |
>40 |
|
>40 |
Isolation @1550nm(dB) |
>40 |
>40 |
|
Accuracy |
|||
Uncertainty(dB) |
±0.5 |
||
Polarization Dependent Loss (dB) |
<±0.25 |
||
Linearity(dB) |
±0.1 |
||
Through Insertion Loss(dB) |
<1.5 |
||
Resolution |
0.01dB |
||
Unit |
dBm/xW |
![产品 5 in 1 PON Power Meter Fiber Cable Testing Instrument](https://cdn.shopifycdn.net/s/files/1/0609/4304/0761/files/H5f46d0b24ea6493db9df0b534897a351y_480x480.jpg?v=1640332544)
Warranty : 3 months.
![5 in 1 PON Power Meter](http://www.splicermarket.com/cdn/shop/products/splicermarket-5-in-1-pon-power-meter.jpg?v=1637926106&width=1445)
![5 in 1 Optical Power Meter](http://www.splicermarket.com/cdn/shop/products/splicermarket-optical-fiber-pon-power-meter.jpg?v=1637926106&width=1445)
![fiber power meter machine](http://www.splicermarket.com/cdn/shop/products/splicermarket-pon-power-meter-fiber-cable-tester.jpg?v=1637926106&width=1445)
![best optical power meter](http://www.splicermarket.com/cdn/shop/products/5-in-1-pon-power-meter-fiber-cable-tester.jpg?v=1637926106&width=1445)
![OPM Optical Power Meter](http://www.splicermarket.com/cdn/shop/products/5-in-1-pon-power-meter-fiber-optic-tester.jpg?v=1637926107&width=1445)
![buy fiber optic power meter](http://www.splicermarket.com/cdn/shop/products/5-in-1-pon-power-meter-VFL-cable-tester.jpg?v=1637926107&width=1445)
